FERRIESDouble ended open ferries
"NEW DOUBLE ENDED OPEN TYPE FERRY" - under construction
- Year 2021
- Location Greece
- Loa 72.78 m 238.78 ft
- Beam 16.00 m
- Draft 2.20 m
A new double ended ferry under construction - of Grade A shipbuilding steeel - completion date due third quarter of 2021. Double bottom from aft to forepeak with collision bulkheads. INSB & Hellenic Merchant of Ships Inspection Service for port areas. Loading and discharging thru fore and stern ramps. 72.78m x 16m x 2.20m draft. Lightship 750t. GRT 800. Full displacement expected to be close to 1265t @ 2.20m draft. Axle load on main deck is 16.5t. 83 private cars OR 14 trucks of 12m each + cars. 4 x marine Caterpillar C-18 heavy duty of 480hp each @ 1800rpm. NB: Could be upgraded to 600bhp @ 1800rpm each!! Baudouin 2 x 110kva gensets. Veth rudder propeller system x 4. 13 knots service speed. 5 crew cabins with 14 berths. 500 passengers. Sprinkler, CO2 + drencher systems. PLEASE CONTACT US FOR MORE DETAILS.
